Scope of application

multi lane packing machine

4 lanes powder packing machine

multi lane packing machine

Features & Mechanical Character :

Feature:

1. English and Chinese screen display, operation is sample.

2. PLC computer system, function is more stable, adjustment any parameters not need stop machine.

3. It can stock ten groups of parameters, simple to change variety.

4. Servo motor drawing film, positing accurately.

5. Temperature independent control system, precision get to 1 degree.

6. Horizontal, vertical temperature control, suitable for various of mix film, PE film bag material etc.

Application:

Applicable For Packing Powder Materials And Granular Materials Such As Coffee Powder, Medicinal Powder,Chemicals Powder, Sugar, Salt, Coffee, MSG, Seasoning,Etc.

Kindly Reminder:

We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.

Control System PLC + Servo + Touch Screen

Cutting Type 1.Flat Cutting, 2.Zigzag Cutting, 3.Continuous Cutting, 4.Customized Special Shap Cutting

Optional device Date Coder, Air-filling Device, Tear Notch Device

Technical Specification :

Model	FBV-480SY	FBV-720SY	FBV-960SY
Measuring	auger filler/scales filler/cups filler etc.
Bag Shape	4 Sides Sealing/back sealing
Packing Speed	25-45 sticks/min/lane ( 2-12 lanes are available)
Max Roll Film Width	480mm	720mm	960mm
Bag Length	50-120mm
Bag Width	30-60mm	30-90mm	30-120mm
Machine Dimension(LWH)	95014701750mm	115316541750mm	141516862130mm
Weight	300KG	400KG	500KG
Power	220V/380V,50/60HZ, 2.8KVA	220V380V,50/60HZ, 4.1KV	220V/380V,50/60HZ 5.5KVA
