FUBO automatic honey filling machine is specially design for filling viscous honey into glass jars and pet bottles, it is also namely honey filler, honey jar packing machine. It is an ideal choice for honey bee factory.
2.Different types of FUBO automatic honey filling machine
There are many models and types of honey filling machine base on different capacity, the filling nozzles number are from one head to 16 heads, and the filling volume is from 5g to 20g, and 100g to 1000g and even 1000g to 5KG.
3.Main structure of honey filler
-20L to 200L Top hopper for option, double Jacket hopper with heating and mixing system for option,
-Main body of machine made by 304SS
-Filling nozzzles, filling nozzles are specially design for shut off and silk cut for honey
-Filling nozzles moving up and down by air cylinder, and servo motor moving up and down for option
-PLC control system, and HMI operation
-Specially made horse and valve for honey, with CIP system connect horse.
4.competitive Advantage of automatic honey filler
There are many advantages of the automatic honey filling machine
-PLC control, operation on touch screen.
-Panasonic servo motor driven , automatic adjust the Filling size on HMI, eg. Users want To fill 500g honey,
users just input the number 500, then the machine will automatic adjust
-it is volumetric by piston, high filling accuracy
-With top Double jacketed heating and mixing tanks which will prevent the honey crystallization after stop working one day or more days
-The automatic honey filling machine also can has the function by CIP system which will connect the users CIP system
-The horse of the honey filler are specially made according to the honey nature, no dead corner, food grade
-The soft tubes or pipes on the honey filler are adapt world brand Toyox from japan
-Specially made rotary valve for viscous honey transfer
5.Main technical
Filling Nozzles : 1-16Nozzles
Production Capacity :800 -5000Bottles Per Hour
Filling Volume ：100-500ml,100ml tp 1000ml
Power :2000W, 220VAC
Accuracy ：±0.1%
Driven :Panasonic Servo Motor
Inerface ：Schneider Touch Screen
6.Automatic honey Filling Machine Main features
a) Products to Fill:
1) hot fill ( 35 ~ 40℃) , cold filling normal temperature
2) Specific Gravity: 1.1 ~1.4 gr/cm3
3) Spreading Chocolate past • Honey • Spreading Cheese paste, Molasses.
b) Bottle type:
1) PET bottle • Quadrant Cross section • Volume 250 ml. • neck 32 mm.
2) Glass Jars & PE, PET Jars • Cylindrical Cross section • Volume 200 ~ 350 ml.
• neck 45 mm.
c) Filling tolerances: +/- max 0.5%
honey Filling Machine basic composition
1.1 Bottles & Jars cleaning by air.
1.2 Automatic bottles feeding and holders (for plastic bottles if need)
1.3 No dripping.
1.4 Output 20 ~ 100 bpm.
1.5 No bottle No fill
1.3 Control panel with PLC touch screen. Malty filling programs saving.
1.4 Double jacketed Hopper with:
• 180 liters volume, • Level Detector. • Electric heaters.
• Product’s temperature detector and control • Stirrer
1.5 Easy dissembling the filling system and nozzles for cleaning.
1.6 Machine’s body of SS 304, all parts in contact with product is SSL 316..
