General instrunctions:
Automatic premade bag liquid packaging machine
Suitable for packing liquid material,such as hand sanitizer,shampoo,detergent,jam,sauce,oil,etc. The
equipment complies with the hygiene standards of food and medical processing machinery. The contact
part of the equipment with 304 stainless steel or other materials that meet food hygiene requirements is
processed to ensure food hygiene and safety and meet GMP standards
Features:
1. The packaging system has a horizontal bag feeding machine
2. It is convenient and simple to put the bag in the bag slot, and is equipped with an automatic pressure bag device;
3. Configure the imported pressure sensing device to achieve the effect of not cutting and unsealing, saving the
packaging bag;
4.Double bag packaging system, packaging speed, weight more accurate, usinghigh-quality accessories to keep the machine lasting and stable;
Shaped of pouches:
doypack, flat pouch, stand up pouch, irregular shape pouch, pouches with spout
Suit for products:
premade pouches filling sealing machines are customized according requirements from customers, machines are suit for packing liquid, powder, solid products etc.
Type |
FBG-180 |
FBG-210 |
FBG-240 |
FBG-330 |
Packing range |
60X80mm & 180X310mm |
90X110mm & 210X310mm |
100X120mm & 240X320mm |
140X180mm & 320X410mm |
Max volume |
1200mL |
1600mL |
2000mL |
4000mL |
Speed |
30-60ppm |
30-60ppm |
30-60ppm |
5-15ppm |
Power |
1.8kw |
2.8kw |
3.4kw |
2.5kw |
Dimension |
1900mm(L) 970mm(W) 1390mm(H) |
2700mm(L) 970mm(W) 1400mm(H) |
3100mm(L) 1010mm(W) 1400mm(H) |
1800mm(L) 1020mm(W) 1300mm(H) |
Weight |
700kg |
900kg |
1800kg |
700kg |
FU-BO is your right choice
